The path-breaking Russian manufacturer
of handheld laser welding machines
The perfect weld without overheating when welding carbon and stainless steel sheets up to 6mm thick, and aluminum plates up to 5mm thick.
SEKIRUS Machines advantages
An elegant and durable seam. Minimal finish machining
Adjustable weld width up to 5mm
HAZ overheating is 3 times lower compared to conventional welding methods
High
welding speed
welding speed
The time spent teaching an operator is minimal
Suitable for processing metal plates up to 6mm thick
Welding wire feeding device (optional)
12 months warranty
The path-breaking Russian manufacturer
of handheld laser welding machines
The perfect weld without overheating when welding carbon and stainless steel sheets up to 6mm thick, and aluminum plates up to 5mm thick.
SEKIRUS Machines advantages
An elegant and durable seam. Minimal finish machining
Adjustable weld width up to 5mm
HAZ overheating is 3 times lower compared to conventional welding methods
High
welding speed
welding speed
The time spent teaching an operator is minimal
Suitable for processing metal plates up to 6mm thick
Welding wire feeding device (optional)
12 months warranty
Samples of handheld laser welding machine operation
Samples of handheld laser welding machine operation
How can a handheld laser welding machine help optimize costs and increase welding operation speed?
SEKIRUS Handheld laser welding machines are reliable equipment that contribute to increased productivity and minimize the cost of training and mastering the welding technology. Our machines are assembled from quality components from European, Chinese and Russian manufacturers. Each machine comes with built-in software with user-friendly interface.
Compared to traditional welding techniques, SEKIRUS welding technology does not require a long-term training period of an operator and guarantees a 4 times faster welding process.
In addition, our machine does not require any rest or forced outage due to overheating during operation, thanks to the reliable built-in water cooling system.
Moreover, a single block with a laser source and a water chiller can be used to operate as a laser metal cutting machine that uses a fiber laser source. Reconfiguration by a qualified technician takes about 20 minutes.
Compared to traditional welding techniques, SEKIRUS welding technology does not require a long-term training period of an operator and guarantees a 4 times faster welding process.
In addition, our machine does not require any rest or forced outage due to overheating during operation, thanks to the reliable built-in water cooling system.
Moreover, a single block with a laser source and a water chiller can be used to operate as a laser metal cutting machine that uses a fiber laser source. Reconfiguration by a qualified technician takes about 20 minutes.
Video of handheld laser welding machine operation
Video of handheld laser welding machine operation
SEKIRUS machines easily weld dissimilar thin-walled metals and create high-strength joints with an elegant seam that requires no finishing.
Traditional TIG / MIG welding techniques
SEKIRUS Manual laser welding technique
Welding speed
Medium
Up to 4 times faster
Quality
Depends on an operator's operations experience
Quality results for the novice as well.
Training period
Long-term
One training session will suffice
Dissimilar Materials
Limited. A reconfiguration is required
Excellent. No reconfiguration is required
Deformation
Easy to deform
Slight deformation or no deformation
HAZ (heat affected zone)
Large
Low
Adjustable weld width
No
Up to 5mm
Sign up for a demonstration of how the SEKIRUS handheld laser welding machine works! Fill in all fields and we will contact you during business hours. By clicking the "Submit request" button, you consent to the processing of personal data and the privacy policy. |
Sign up for a demonstration of how the SEKIRUS handheld laser welding machine works! Fill in all fields and we will contact you during business hours. By clicking the "Submit request" button, you consent to the processing of personal data and the privacy policy. |
The key part of the machine is a laser source
SEKIRUS Handheld laser welding machines are based on ytterbium-doped fiber laser sources of Russian and Chinese manufacturers.
Based on your technical requirements we supply welding machines with laser sources
IPG (Russia), SEKIRUS (PRC), Raycus (PRC), JPT (PRC), MAX (PRC).
SEKIRUS Handheld laser welding machines are based on ytterbium-doped fiber laser sources of Russian and Chinese manufacturers.
Based on your technical requirements we supply welding machines with laser sources
IPG (Russia), SEKIRUS (PRC), Raycus (PRC), JPT (PRC), MAX (PRC).
The key part of the machine is a laser source
SEKIRUS Handheld laser welding machines are based on ytterbium-doped fiber laser sources of Russian and Chinese manufacturers.
Based on your technical requirements we supply welding machines with laser sources
IPG (Russia), SEKIRUS (PRC), Raycus (PRC), JPT (PRC), MAX (PRC).
SEKIRUS Handheld laser welding machines are based on ytterbium-doped fiber laser sources of Russian and Chinese manufacturers.
Based on your technical requirements we supply welding machines with laser sources
IPG (Russia), SEKIRUS (PRC), Raycus (PRC), JPT (PRC), MAX (PRC).
SEKIRUS handheld laser welding machine technical data
Fiber connector
QBH
QBH
Laser power
Up to 3kW
Up to 3kW
Wavelength
1064nm ~ 1080nm
1064nm ~ 1080nm
Weld width
0.2mm~5mm
0.2mm~5mm
Collimator focal length
50mm
50mm
Focal length
120mm/150mm
120mm/150mm
Shielding glass
D20х2
D20х2
Cooling method
Water chiller
Water chiller
Weight
300kg
300kg
Welding gun's weight
1.2kg
1.2kg
Working mode:
6 modes for choice:
1. 'Dot'
2. 'Line'
3. 'Triangle'
4. 'Circle'
5. 'Hourglass'
6. 'Double-circle'
6 modes for choice:
1. 'Dot'
2. 'Line'
3. 'Triangle'
4. 'Circle'
5. 'Hourglass'
6. 'Double-circle'
Software for SEKIRUS Laser welding machine
SEKIRUS handheld laser welding machines are controlled by a controller. The welding mode setting is carried out by the operator via the color touch screen.
The program module has been specially developed by our specialists to operate the handheld laser welding machine SEKIRUS.
The equipment is provided with the built-in software and program modules that are required for proper functioning laser welding machines. The software is available under a free open licence.
To download the user manual "Control System Software for SEKIRUS Welding machine" click on the "Download" button.
The program module has been specially developed by our specialists to operate the handheld laser welding machine SEKIRUS.
The equipment is provided with the built-in software and program modules that are required for proper functioning laser welding machines. The software is available under a free open licence.
To download the user manual "Control System Software for SEKIRUS Welding machine" click on the "Download" button.
SEKIRUS Handheld laser welding machine's price
Optional equipment and accessories
Welding consumables
Warranty support and service
If any problems with the machine occur, please, contact our support team. We provide warranty service of our equipment and repair of other handheld laser welding machines purchased on AliExpress or from other Chinese suppliers.
The vast stocks of consumables, laser sources and cutting heads, as well as an excellent operation of the logistics department allow us to accomplish these tasks at your earliest convenience.
The vast stocks of consumables, laser sources and cutting heads, as well as an excellent operation of the logistics department allow us to accomplish these tasks at your earliest convenience.
Service Request
To contact our service center, please, call +7 931 229 40 75 or send your request using the following form:
10 simple steps to buy a handheld laser welding machine
Choose a model
Please, call us +7 931 229 40 75 or contact us on WhatsApp or e-mail info@lazernaya-svarka.ru
Demonstration of equipment
In order to make sure that the equipment is optimally suited to your application, we carry out a testing machining of your samples online, in our showroom, or at the production site.
Formation of a contract
Send the requisites. Have the contract approved by the legal department.
Make prepayment
Make a prepayment 80%.
Manufacturing the machine starts from now on.
Manufacturing the machine starts from now on.
Preparatory works
Prepare your workshop for the installation of the machine by following our instructions.
Second payment
Make a payment 15% after receiving notification that your machine is ready for shipment. We will arrange your machine transportation.
Installation
Unload the equipment and install it in the workshop.
Start-up
Our engineer instructs you in machine operation and safety at the prepared site.
Training
We provide for full-time and part-time training of your operators. One-day training session will suffice.
Final payment
All work is done - the machine works, operators are trained, documents are provided. Rest payment is 5%.
We also offer CNC laser machines
Contacts
St. Petersburg,
st. Kibalchicha, 20
st. Kibalchicha, 20
SEKIRUS equipment on the map
Contacts
St. Petersburg,
st. Kibalchicha, 20
st. Kibalchicha, 20
SEKIRUS equipment on the map
Customer reviews
SEKIRUS equipment at trade fairs
For the first time the SEKIRUS handheld laser welding machine was presented in 2019 at two international exhibitions in Moscow – "Weldex" and "Technoforum".
In 2021 the SEKIRUS handheld laser welding machine based on an IPG laser source (Russia) was presented at the exhibition during the Innovation Day of the Russian Ministry of Defense in "Technopolis ERA".
In 2021 the SEKIRUS handheld laser welding machine based on an IPG laser source (Russia) was presented at the exhibition during the Innovation Day of the Russian Ministry of Defense in "Technopolis ERA".
